| 技术特性 | |
| 额定电压 | 250v ac，dc |
| 额定电流 | 3a ac, dc |
| 接触电阻 | 20m max |
| 绝缘电阻 | 1000m min |
| 耐压 | 1000v ac/minute |
| 环境温度 | -25°c〜 85°c |
| 适用线规 | awg#28〜#22 |
| 材料 | |
| 插座 | 尼龙ul94-v0(2) |
| 插头 | 尼龙ul94-v0(2) |
| 端子 | 磷青铜,镀锡 |
| 电路 | 类型 | 尺寸(mm) | |
| a | b | ||
| 2 | lp-2y | 2.5 | 5.3 |
| 3 | lp-3y | 5.0 | 7.8 |
| 4 | lp-4y | 7.5 | 10.3 |
| 5 | lp-5y | 10.0 | 12.8 |
| 6 | lp-6y | 12.5 | 15.3 |
| 7 | lp-7y | 15.0 | 17.8 |
| 8 | lp-8y | 17.5 | 20.3 |
| 9 | lp-9y | 20.0 | 22.8 |
| 10 | lp-10y | 22.5 | 25.3 |
| 11 | lp-11y | 25.0 | 27.8 |
| 12 | lp-12y | 27.5 | 30.3 |
| 13 | lp-13y | 30.0 | 32.8 |
| 14 | lp-14y | 32.5 | 35.3 |
| 15 | lp-15y | 35.0 | 37.8 |
| 电路 | 类型 | 尺寸(mm) | |
| a | b | ||
| 2 | lp-2r | 2.5 | 7.5 |
| 3 | lp-3r | 5.0 | 10.5 |
| 4 | lp-4r | 7.5 | 12.5 |
| 5 | lp-5r | 10.5 | 15.0 |
| 6 | lp-6r | 12.5 | 17.5 |
| 7 | lp-7r | 15.0 | 20.0 |
| 8 | lp-8r | 17.5 | 22.5 |
| 9 | lp-9r | 20.0 | 25.0 |
| 10 | lp-10r | 22.5 | 27.5 |
| 11 | lp-11r | 25.0 | 30.0 |
| 12 | lp-12r | 27.5 | 32.5 |
| 13 | lp-13r | 30.0 | 35.0 |
| 14 | lp-14r | 32.5 | 37.5 |
| 15 | lp-15r | 35.0 | 40.0 |
