| specifications | |
| rated voltage | 250v ac，dc |
| rated current | 5a ac, dc |
| contact resistance | 20m max |
| insulation resistance | 1000m min |
| withstand voltage | 1500v ac/minute |
| ambient temperature | -25°c〜 85°c |
| wire range | awg#28〜#20 |
| materials | |
| receptacle housing | nylon ul94-v0(2) |
| plug housing | nylon ul94-v0(2) |
| terminal | phosphor bronze, tin plated |
| circuits | type | dimensions(mm) | |
| a | b | ||
| 2 | 5500-2y | 3.7 | 8.7 |
| 3 | 5500-3y | 7.4 | 12.4 |
| circuits | type | dimensions(mm) | |
| a | b | ||
| 2 | 5600-2r | 3.7 | 11.3 |
| 3 | 5600-3r | 7.4 | 15.0 |
