| specifications | |
| rated voltage | 300v ac，dc |
| rated current | 13a ac, dc |
| contact resistance | 20m max |
| insulation resistance | 1000m min |
| withstand voltage | 1500v ac/minute |
| ambient temperature | -25°c〜 85°c |
| wire range | awg#20〜#16 |
| materials | |
| housing | nylon ul94-v0(2) |
| wafer | nylon ul94-v0(2) |
| terminal | phosphor bronze, tin plated |
|
wafer |
plug housing |
mounting measurement |
|
dl63001-2a(42002-2a)
|
dl63001-2y(42021-2y)
|
|
|
dl63001-3a(42002-3a)
|
dl63001-3y(42021-3y)
|
|
|
dl63001-4a(42002-4a)
|
dl63001-4af(42002-4af)
|
|
|
dl63001-4g(42002-4g)
|
dl63001-4y(42021-4y)
|
|
|
dl63001-6a(42002-6a)
|
dl63001-6y(42021-6y)
|
|
|
dl63001-9a(42002-9a)
|
dl63001-9y(42021-9y)
|
|
|
dl63001-12a(42002-12a)
|
dl63001-12y(42021-12y)
|
|
|
dl63001-15a(42002-15a)
|
dl63001-15y(42021-15y)
|
|
